92815 – Warn Zeon 10-S Platinum Winch With Synthetic Rope

92815 – Warn Zeon 10-S Platinum Winch with Synthetic Rope

The DC2000 hoist combines a powerful permanent magnet DC motor with robust sealing and our proven 3-stage all metal gear train. Permanent grease lubrication means years of trouble free service. All WARN hoists incorporate an automatic mechanical brake that holds full rated load. The durable powder coated finish stands up to the elements and looks great. The hoist is built on a compact midsize framed with integrated tie bars that’s easy to install.

Features & Benefits:

• 10,000 Pound Single-Line Pulling Capacity
• Convertible Control Pack Can Be Attached To The Winch Or Remotely Mounted, Allowing For Various Winch Mounting Options And Looks
• Updated Planetary Gear Train And Series-Wound Motor Deliver Fast, Quiet, And Reliable Pulling Power
• Tough Enough To Tackle Anything You Will, With A Look That Is Advanced, Capable And Strong
• Large Diameter Winch Drum Reduces Rope Wear, Is Light Weight, And Has An Integrated Rope Anchor For Easy Rope Installation
• Limited Lifetime Warranty

Attributes:

• Winch Rating: 10000 Pound
• Recommended Use: Vehicle Recovery
• Operation Type: Electric
• Mount Type: Fixed Mount
• Voltage: 12 Volt
• Free Spooling: Yes
• Line Length (FT): 100 Feet
• Line Material: Synthetic
• Remote Type: Wireless
• Universality: Fully Universal
• Mounting Pattern Size: 11 Inch length X 4-1/2 Inch Width
• Brake Type: Automatic Cone
• Max Amp Draw: 465 Amp Draw At 10000 Pound
• Gear Reduction Ratio: 162:1
• Includes Mounting Hardware: Yes
• Thermal Shutoff: No
• Color: Black
• Fairlead Type: Hawse
• Line Speed At Max Pull: 5.6 Feet Per Minute At 10000 Pound
• Electrical Control Type: Contactors
• Motor Type: Series Wound
• Drive Gear Type: Planetary
• Line Diameter (IN): 3/8 Inch
• Mounting Hole Quantity: 4
• Drum Material: Aluminum
• Estimated Install Time (Hours): 2
